Ban30 Radar 15m

The Ban30 Radar is a mid-range sensor that provides reliable detection and position feedback in extreme applications, using high frequency radio waves from an internal antenna.



Operating in the 24 GHz ISM band using FMCW (time-of-flight) technology, the Ban30 Radar is the ideal solution for extra wide boom gates in excess of 6m and up to 15 meters where loop detectors and PE beams are not an option.

Please Note: Rotech Automation will configure the length of detection and accurate measurement needs to be provided at time of order.
Make an enquiry

The Ban30 Radar is easy to install and Telecom approved in Australia.  With a 10-30V DC, the sensor can be configured to sense objects up to a specific distance and ignoring objects beyond this distance.  It detects Metal such as Cars, Trucks, Bikes and organic material (pedestrian).

The Ban30 Radar includes the following features:

  • Adjustable sensing range: from 6m to up to 15m
  • FMCW radar detects moving and stationary objects
  • Adjustable sensing field to ignores objects beyond setpoint
  • Easy setup and configuration of range, sensitivity, and output using the Banner Radar configuration Software
  • Telecom approved for Europe, UK, Australia, New Zealand, China, and Japan
  • Sensing functions are immune to wind, fog, steam, extreme temperature changes, resistant to rain and snow
  • Rugged IP67 housing withstands harsh environments -40°C to +65°C



Please Note: Rotech Automation will configure the length of detection and accurate measurement needs to be provided at time of order. Please call us for more information.

For more information download our product datasheet.

Feature
Specification
Power
DC
Sensing Beam
Radar
Operating Frequency
122GHz
IP Rating
IP67
Supply Voltage
10-30V DC
Max Sensing Distance
15m
Operating Temp.
–40°C to +65°C
Minimum Response Time
6ms

For more information download our product datasheet.

For information about installation and operating instructions please download our PDF.
