EVA 4 to 8M INTENSIVE USE BOOM GATES

4 to 8 Metre Intensive Use Boom Gates – 100% Duty Cycle – High quality – European manufactured



The EVA is a 24V intensive use automatic boom gates that offers precise speed control, an easily programmed multi-function digital controller, and ultra-responsive performance.  Top access to the control panel allows for easy and fast programming.  Features built-in radio receiver and battery charger with automatic testing of safety devices at each movement.

Make an enquiry
This is a quality European-made boom gate that meets all international safety standards.
The simple to adjust boom arm balancing system makes these boom gates quick and straight forward to install.
The Beninca EVA comes in two size cabinet with arms option of 4 to 6 meters and in a bigger version in 7 and 8m arms.

Both models include the following features:

  • Electromechanical barrier for intensive use with control unit, battery charger and extended range switching power supply from 100 to 250 VAC.
  • Flashing Cabinet Light
  • An integrated absolute encoder ensures greater precision in slowdowns and advanced control of the boom movement to ensures it never loses the reference position of the boom at time of power failure.
  • Fast-acting manual release in case of power failure
  • Reduced energy use on standby
  • Multiple output for connectivity to safety devices (PE Beams, Radars, Boom arms LED lights…)
  • Electronic collision sensing reverses boom pole on contact
  • Right or left hand – the barrier can be easily re-handed.
  • Optional LED flashing lights on the boom arm
  • Battery backup charger included
  • Solar Option available



For more information download our product datasheet.



Specification
EVA 4-5
EVA 6-7
EVA 8
Power Supply
240 Vac
240 Vac
240 Vac
Motor Supply
24V DC
24V DC
24V DC
Max absorbed current
1.6 A
1.6 A
1.6 A
Power consumption in stand-by
40 m/A
40 m/A
40 m/A
Torque
205 Nm
285 Nm
285 Nm
Opening time
3-6 seconds
3-6 seconds
3.5-6 seconds
Duty Cycle
Intensive Use
Intensive use
Intensive use
Protection Level
IP44
IP44
IP44
Operating Temperature
-20oC / +50oC
-20oC / +50oC
-20oC / +50oC

For more information download our product datasheet.

Download our information installation and operating instructions
